Area Security Radar GSR-W60

The GSR-W60 is an intelligent wide-angle area security radar with a detection range of 60 meters and a detection Angle of 120°. The radar will detect and warn when the target enters the defense area, and judge the accurate position of the target through the distance, Angle and speed of the target. It can integrate the video for target recheck and judge whether it is the target that needs alarm. Using FMCW modulation mode, with high detection accuracy; The unique digital beam synthesis (DBF) technology can greatly improve the anti-jamming ability of the radar system, with high precision Angle resolution and low speed detection ability. Through the back-end signal processing and pattern recognition algorithm, it can distinguish human and vehicle targets, and effectively filter out the interference of insects, birds and other animals.

PRODUCT FEATURE

■ Moving target detection radar operating in 60GHz-ISM band
■ It can detect extremely slow moving targets (-8.9~8.9m/s) and filter the interference of trees, grass and other plants
■ Advanced DBF technology accurately detects the target's azimuth Angle, pitch Angle, distance and other information
■ Protection class IP67 for outdoor applications

■ Ports Rich RJ45/RS485

■ Accord to ROHS Standard
