Water Aerial Aurvey Radar WSR-W1500

WSR-W1500 is A K-band wide-beam regional water navigation radar, a regional water track monitoring radar with the distance of the sounding ship up to 1500 meters, adopts the highly complex FMCW modulation mode, Using TBD, PDA, JPDA, MIMO, MTD, STAP, EKF and micro-Doppler sensor, based on neural network to establish radar environment cognition and other advanced technologies, can accurately detect the distance and Angle information of moving targets, effectively filter water wave false positiv, support 1 channel alarm output, adopt reliable transceiver integration technology, It has the characteristics of high sensitivity, wide detection range, strong environmental adaptability, accurate detection, easy integration, stable performance and high cost performance. By detecting and identifying targets within the warning range of illegal intrusion, the early warning function can provide all-day and all-weather security guarantee and flight path monitoring for the surrounding environment of important facilities.

PRODUCT FEATURE

■ Work in 24GHz-ISM-Band for the detection of moving targets

■ The farthest target detection distance is 1500m, and the wide-angle detection is 90°

■ Can detect the size of ships in the water, and remove birds, trees, water and other interference

■ Support radar communication protocol, SDK, web API and other protocols and development kits, flexible development

■Actively search for target information, guide camera picture positioning, and drive sound and light alarm on site
